2014 Mazda3 Maintenance Light Reset & Specs

Automotive, How To Wednesdays No Comments »

MAZDA3 Sedan

The 2014 MAZDA3 for North America is offered in a gasoline model.  After performing the oil change the maintenance data will need to be reset.  There are 2 different reset methods depending on if the vehicle has a touch screen:

Menu Button
Menu Button
  1. Press and hold the TRIP button with the ignition switched off.

  2. Continue to hold the TRIP button and switch the ignition on.

  3. After 5 seconds the master warning light will flash for a few seconds to indicate the reset is complete.

  4. Turn the ignition off and then start the engine to verify the indicator has been reset.

Master Warning Light
Master Warning Light

Touch Screen Instructions:

Applications Icon
Applications Icon
  1. Turn the ignition to run (one position before starting the engine).

  2. Select the Applications (A) icon.

  3. Select Maintenance to display the maintenance list screen and select Oil Change.

  4. Select Reset and follow the prompts.

  5. Turn the ignition off and then start the engine to verify the indicator has been reset.

MAZDA3 Maintenance Warning Light
Maintenance Due

When doing the oil change and topping up fluids you will need to use the following specifications:

Engine Size

4 Cyl. 2.0L Gas

4 Cyl. 2.5L Gas

Motor Oil

OW-20

OW-20

Oil Capacity w/Filter

4.4 US qt. (4.2L)

4.8 US qt. (4.5L)

Clutch Fluid

SAE J1703 or FMVSS116 DOT-3

SAE J1703 or FMVSS116 DOT-3

Brake Fluid

SAE J1703 or FMVSS116 DOT-3

SAE J1703 or FMVSS116 DOT-3

Engine Coolant

Mazda Genuine FL22

Mazda Genuine FL22

Automatic Transmission

Mazda Genuine ATF FZ

Mazda Genuine ATF FZ

Manual Transmission

GL-4/ 75W-80

GL-4/ 75W-80

mazda3-2014-52

You can cross reference the following Purolator filter numbers for your own application:

Engine Size

4 Cyl. 2.0L Gas

4 Cyl. 2.5L Gas

Oil Filter

L14612

L14612

Air Filter

A26280

A26280

Cabin Filter

*Dealer Part

*Dealer Part

Always consult the owner’s manual or manufacturer prior to any service.

*At the time of this posting being published

http://www.oilreset.com

2014 Fiat 500 Maintenance Light Reset & Specs

Automotive, How To Wednesdays No Comments »
2014 Fiat 500

2014 Fiat 500

The 2014 Fiat 500 for North America is offered in a gasoline model.  After performing the oil change the maintenance data will need to be reset.  Follow these steps to reset this light:

  1. Turn the ignition to run (one position before starting the engine).

  2. Fully depress the accelerator pedal slowly three times within 10 seconds.

  3. Turn the ignition off and then start the engine to verify the indicator has been reset.

When doing the oil change and topping up fluids you will need to use the following specifications:

Engine Size

4 Cyl. 1.4L/ 1.4L Turbo Gas

Motor Oil

*5W30 or 5W40 Synthetic

*Refer to oil filler cap for correct SAE grade

Oil Capacity w/Filter

4 US qt. (3.8L)

Clutch Fluid

MOPAR DOT 3

Brake Fluid

MOPAR DOT 3

Engine Coolant

MOPAR antifreeze/coolant

Automatic Transmission

MOPAR AW-1 ATF

Manual Transmission

MOPAR C635 DDCT/MTX

You can cross reference the following Purolator filter numbers for your own application:

Engine Size

4 Cyl. 2.5L Gas

Oil Filter

L16162

Air Filter

*Dealer Part

Cabin Filter

*Dealer Part

1.4L 4 Cyl. Gas

1.4L 4 Cyl. Gas



Always consult the owner’s manual or manufacturer prior to any service.

*At the time of this posting being published

http://www.oilreset.com

2014 Mazda6 Maintenance Light Reset & Specs

Automotive, How To Wednesdays No Comments »
Mazda6 Steering Wheel

Mazda6 Steering Wheel

The 2014 Mazda6  is offered in a gasoline model.  After performing the oil change the maintenance data will need to be reset.  Follow these steps to reset this light:

  1. Turn the ignition to run (do not start the engine).

  2. Press the UP or DOWN part of the INFO switch to highlight the SETTINGS menu and press the INFO button to confirm.

  3. Scroll to MAINTENANCE and press the INFO button to confirm.

  4. Scroll to the item that needs to be reset  (SCHEDULED, TIRE ROTATION, TIRE PRESSURE) and confirm with the INFO button.

  5. Scroll to SET TIME or SET DISTANCE and confirm with the INFO button.

  6. Turn the ignition off and then start the engine to verify the indicator has been reset.

mazda6reset
Reset Instructions

In case the maintenance info is not active it can be setup by following this procedure:

Maintenance Info Setup
Maintenance Info Setup

When doing the oil change and topping up fluids you will need to use the following specifications:

Engine Size

4 Cyl. 2.5L Gas

Motor Oil

*0W20

*Recommended for USA and Canada

Oil Capacity w/Filter

4.8 US qt. (4.5L)

Clutch Fluid

SAE J1703 or FMVSS116 DOT-3

Brake Fluid

SAE J1703 or FMVSS116 DOT-3

Engine Coolant

Mazda Genuine Coolant

Automatic Transmission

Mazda Genuine ATF FZ

Manual Transmission

API GL-4 or SAE 75W-80

You can cross reference the following Purolator filter numbers for your own application:

Engine Size

4 Cyl. 2.5L Gas

Oil Filter

L14612

Air Filter

A26280

Cabin Filter

*Dealer Part

4 Cyl. 2.5L Gas Engine

4 Cyl. 2.5L Gas Engine

Always consult the owner’s manual or manufacturer prior to any service
*At the time of this posting being published
Written by OilReset

2014 Honda Accord Maintenance Light Reset & Specs

Automotive, How To Wednesdays No Comments »
2014 Honda Accord Sedan

2014 Honda Accord Sedan

2014 Honda accord engine

4 Cyl. 2.4L Engine

2014 honda accord interior

2014 Honda Accord Interior

The 2014 Honda Accord sedan/coupe is offered in a gasoline model.  After performing an oil change the maintenance data will need to be reset using this method for vehicles without the multi-information display:

1. Turn the ignition to run (one position before starting engine).

2. Display the engine oil life by repeatedly pressing the SELECT/RESET knob.

3. With the oil life displayed, press and hold the SELECT/RESET knob for 10 seconds.  The engine oil life indicator and the maintenance codes blink.

4. Press the SELECT/RESET knob for 5 seconds.  The maintenance codes will disappear and the oil life will reset to 100%.

5. Turn the ignition off and then start the engine to verify the indicator has been reset.

Reset for vehicles with the multi-information display:

1. Turn the ignition to run (one position before starting engine).

2. Press the (up/down) button to select Vehicle Settings, then press the SEL/RESET button.

3. Press the (up/down) button until Maintenance Reset appears on the display.

4. Press the SEL/RESET button – the oil life reset mode is displayed on the multi-information display.

5. Select Reset with the (up/down) button, then press the SEL/RESET button. The displayed maintenance items disappear, and the engine oil life display returns to 100%.

6. Turn the ignition off and then start the engine to verify the indicator has been reset.

When doing the oil change and topping up fluids you will need to use the following specifications:

Engine Size

4 Cyl. 2.4L

6 Cyl. 3.5L

Motor Oil

0W20

OW20

Oil Capacity w/Filter

4.4 US qt. (4.2L)

4.5 US qt. (4.3L)

Brake Fluid

Honda Heavy Duty Brake Fluid DOT 3

Honda Heavy Duty Brake Fluid DOT 3

Clutch Fluid

Honda Heavy Duty Brake Fluid DOT 3

N/A

Engine Coolant

Honda Long-Life Antifreeze/ Coolant Type 2

Honda Long-Life Antifreeze/ Coolant Type 2

Manual Transmission

Honda Manual Transmission Fluid

N/A

Automatic Transmission

HCF-2

Honda ATF DW-1

You can cross reference the following Pennzoil filter numbers for your own application:

Engine Size

4 Cyl. 2.4L

6 Cyl. 3.5L

Oil Filter

HPZ-37

HPZ-37

Air Filter

A26282

A26283

Cabin Filter

PC-58

PC-58

Written by OilReset Http://www.oilreset.com

1995 to 2006 Mercedes Sprinter/ Dodge Sprinter Maintenance Light Reset Instructions

Automotive, How To Wednesdays 1 Comment »
Sprinter Instrument Cluster

Sprinter Instrument Cluster

After performing an oil change on the Mercedes Sprinter or Dodge Sprinter the maintenance data can be reset by doing the following:

1) Turn the ignition to run (one position before starting the engine).

2) Press the “km” or “mi” button 2 times.  Turn the ignition off.

3) Press and hold the “km” or “mi” button and continue to hold while turning the ignition to run (one position before starting the engine).

4) Continue to hold the button until a sound is made and the new distance or time is displayed for the next service (about 10 seconds).

5) Turn the ignition off and then start the engine to verify the indicator has been reset.

These instructions are applicable for Sprinter models between 1995 and 2006 with the above pictured instrument cluster.

2007 to 2013 Mercedes Sprinter or Dodge Sprinter Maintenance Light Reset Instructions

Automotive, How To Wednesdays No Comments »
Instrument Clusters

Instrument Clusters

From 2007 onwards the reset instructions will depend on if the vehicle has steering wheel controls or not (please reference photos).   After performing an oil change on the Mercedes Sprinter or Dodge Sprinter the maintenance data can be reset by doing the following:

Without Steering Wheel Controls:

1) Turn the ignition to run (one position before starting the engine).  Wait until the odometer reading is shown.

2) Press and hold the “O” button until a beep sounds (about 30 seconds).

3) Press button “M” repeatedly until “rESET 229.5″ (depending on your model you may seem different numbers after rESET which is normal) is shown with the oil can symbol.

4) Press button “O” for 3 seconds, release and press again.

5) Turn the ignition off and then start the engine to verify the indicator has been reset.

With Steering Wheel Controls

Steering Wheel Controls

Steering Wheel Controls

1) Turn the ignition to run (one position before starting the engine).  Wait until the odometer reading is shown or press the FORWARD or BACK button until displayed.

2) Press the arrow UP or DOWN button several times until “service scope x in xxx km” appears.

3) Press button “O” in the instrument cluster until a beep sounds (about 30 seconds).

4) Press the BACK button once.

5) Press the arrow UP or DOWN button until “Service in xxx km” appears.

6) Press button “O” on the instrument cluster.  The menu “Carry out” appears.

7) Press the arrow UP or DOWN button until “Oil types” appears.

8) Press the “+” or “-” buttons until the desired *oil specification is shown.

9) Confirm the oil type with the arrow UP or DOWN button.

10) Press the “O” button until “Service confirmed” appears (about 3 seconds).

11)  Turn the ignition off and then start the engine to verify the indicator has been reset.

*Oil Specification Codes

Diesel engine with long oil change interval: Qual. 228.51 (older instrument clusters 229.5)

Diesel engine with short oil change interval: Qual. 229.31 (older instrument clusters (229.3)

Gas engine with long oil change interval: Qual. 229.5

Gas engine with short oil change interval: Qual. 229.3



2013 Toyota Venza Maintenance Light Reset & Specs

Automotive, How To Wednesdays No Comments »
2013 Toyota Venza

2013 Toyota Venza

The 2013 Toyota Venza is offered in a gasoline model.  After performing the oil change the maintenance data will need to be reset.  Follow these steps to reset this light:

1. Start the engine and bring up the trip meter A reading.

Vehicles with smart key system:

2. Turn the “ENGINE START STOP” switch off.

3. While pressing the Trip Meter reset button, press the “ENGINE START STOP” switch once (do not start engine).

4. Continue to press and hold the button until the trip meter displays “000000″.

5. Turn the ignition off and then start the engine to verify the indicator has been reset.

Vehicles without smart key system:

2. Turn the ignition switch off.

3. While holding down the trip meter reset knob turn the ignition to run (one position before starting engine).

4. Hold down knob for at least 5 seconds.  The odometer indicates “000000″ and the light goes off.  If the system fails to reset, the light will continue flashing.

5. Turn the ignition off and then start the engine to verify the indicator has been reset.

When doing the oil change and topping up fluids you will need to use the following specifications:

Engine Size

4 Cyl. 2.7L Gas

6 Cyl. 3.5L Gas

Motor Oil

0W20

0W20

Oil Capacity w/Filter

4.6 US qt. (4.4L)

6.4 US qt. (6.1L)

Brake

Dot 3

Dot 3

Engine Coolant

Toyota Super Long Life Coolant

Toyota Super Long Life Coolant

Automatic Transmission

Toyota Genuine ATF WS

Toyota Genuine ATF WS

Rear Differential

Hypoid gear oil API GL-5

Above 0°F (-18°C): SAE 90

Below 0°F (-18°C): SAE 80W or

SAE 80W-90

Hypoid gear oil API GL-5

Above 0°F (-18°C): SAE 90

Below 0°F (-18°C): SAE 80W or

SAE 80W-90

Transfer Case

Hypoid gear oil API GL-5

Above 0°F (-18°C): SAE 90

Below 0°F (-18°C): SAE 80W or 80W-90

Hypoid gear oil API GL-5

Above 0°F (-18°C): SAE 90

Below 0°F (-18°C): SAE 80W or 80W-90

You can cross reference the following Purolator filter numbers for your own application:

Engine Size

4 Cyl. 2.7L Gas

6 Cyl. 3.5L Gas

Oil Filter

L25608

L25608

Air Filter

A35649

A45650

Cabin Filter

C35667

C35667

6 Cyl. 3.5L Gas

6 Cyl. 3.5L Gas



















Always consult the owner’s manual or manufacturer prior to any service

2013 Toyota Tacoma Maintenance Light Reset & Specs

Automotive, How To Wednesdays No Comments »
2013 Toyota Tacoma

2013 Toyota Tacoma

The 2013 Toyota Tacoma is offered in a gasoline model.  After performing the oil change the maintenance data will need to be reset.  Follow these steps to reset this light:

1. Turn the ignition to run (one position before starting engine).

2. Ensure trip meter A reading is shown.  Turn ignition off.

3. While holding down the trip meter reset knob turn the ignition to run (one position before starting engine).

4. Hold down knob for at least 5 seconds.  The odometer indicates “000000″ and the light goes off.  If the system fails to reset, the light will continue flashing.

5. Turn the ignition off and then start the engine to verify the indicator has been reset.

When doing the oil change and topping up fluids you will need to use the following specifications:

Engine Size

4 Cyl. 2.7L Gas

6 Cyl. 4.0L Gas

Motor Oil

0W20

5W30

Oil Capacity w/Filter

6.1 US qt. (5.8L)

2WD

4.8 US qt. (4.5L)

4WD

5.5 US qt. (5.2L)

Brake/Clutch Fluid

Dot 3

Dot 3

Engine Coolant

Toyota Super Long Life Coolant

Toyota Super Long Life Coolant

Power Steering Fluid

ATF DEXRON II or III

ATF DEXRON II or III

Automatic Transmission

4 Speed Model

Toyota Genuine ATF Type T-IV

5 Speed Model

Toyota Genuine ATF WS

4 Speed Model

Toyota Genuine ATF Type T-IV

5 Speed Model

Toyota Genuine ATF WS

Manual Transmission

SAE 75W90

SAE 75W90

Front Differential

Toyota Genuine Differential gear oil LT

75W-85 GL-5 or equivalent

Toyota Genuine Differential gear oil LT

75W-85 GL-5 or equivalent

Rear Differential

Toyota Genuine Differential gear oil LT

75W-85 GL-5 or equivalent

Toyota Genuine Differential gear oil LT

75W-85 GL-5 or equivalent

Transfer Case

SAE 75W90

SAE 75W90

You can cross reference the following Purolator filter numbers for your own application:

Engine Size

4 Cyl. 2.7L Gas

6 Cyl. 4.0L Gas

Oil Filter

L10241

L10241

Air Filter

A35625

A35578

Cabin Filter

C35644

C35644

4 Cyl. 2.7L Gas

4 Cyl. 2.7L Gas



















Always consult the owner’s manual or manufacturer prior to any service

2013 Toyota Tundra Maintenance Light Reset & Specs

Automotive, How To Wednesdays No Comments »
2013 Toyota Tundra

2013 Toyota Tundra

The 2013 Toyota Tundra is offered in a gasoline model.  After performing the oil change the maintenance data will need to be reset.  Follow these steps to reset this light:

1. Turn the ignition to run (one position before starting engine).

2. Ensure Trip Metre A reading is shown.  Turn the ignition off.

3. While holding down the trip meter reset knob turn the ignition to run (one position before starting engine).

Without multi-information display

4. Continue to press and hold the button until the trip meter displays “000000″.

With multi-information display

4. Continue to press and hold the button until “MAINT REQD RESET MODE COMPLETE” appears on the multi-information display.

5. Turn the ignition off and then start the engine to verify the indicator has been reset.

 When doing the oil change and topping up fluids you will need to use the following specifications:

Engine Size

6 Cyl. 4.0L Gas

8 Cyl. 4.6L Gas

8 Cyl. 5.7L Gas

Motor Oil

0W20

0W20

0W20

Oil Capacity w/Filter

6.4 US qt. (6.1L)

7.9 US qt. (7.5L)

7.9 US qt. (7.5L)

Brake Fluid

Dot 3

Dot 3

Dot 3

Engine Coolant

Toyota Super Long Life Coolant

Toyota Super Long Life Coolant

Toyota Super Long Life Coolant

Power Steering Fluid

ATF DEXRON II or III

ATF DEXRON II or III

ATF DEXRON II or III

Automatic Transmission

Toyota Genuine ATF WS

Toyota Genuine ATF WS

Toyota Genuine ATF WS

Front Differential

Toyota Genuine Differential gear oil LT

75W-85 GL-5 or equivalent

Toyota Genuine Differential gear oil LT

75W-85 GL-5 or equivalent

Toyota Genuine Differential gear oil LT

75W-85 GL-5 or equivalent

Rear Differential

Toyota Genuine Differential gear oil LT

75W-85 GL-5 or equivalent

Toyota Genuine Differential gear oil LT

75W-85 GL-5 or equivalent

Toyota Genuine Differential gear oil LT

75W-85 GL-5 or equivalent

Transfer Case

SAE 75W90

SAE 75W90

SAE 75W90

You can cross reference the following Purolator filter numbers for your own application:

Engine Size

6 Cyl. 4.0L Gas

8 Cyl. 4.6L Gas

8 Cyl. 5.7L Gas

Oil Filter

L25609

L25702

L25702

Air Filter

A55799

A55799

A55799

Cabin Filter

C35667

C35667

C35667

8 Cyl. 5.7L

8 Cyl. 5.7L

2013 Toyota Sequoia Maintenance Light Reset & Specs

Automotive, How To Wednesdays No Comments »

2013 Toyota SequoiaThe 2013 Toyota Sequoia is offered in a gasoline model.  After performing an oil change the maintenance data will need to be reset.  Follow these steps to reset this light:

1. Turn the ignition to run (one position before starting engine).

2. Ensure Trip Metre A reading is shown.  Turn the ignition off.

3. While holding down the trip meter reset knob turn the ignition to run (one position before starting engine).

Without multi-information display

4. Continue to press and hold the button until the trip meter displays “000000″.

With multi-information display

4. Continue to press and hold the button until “MAINT REQD RESET MODE COMPLETE” appears on the multi-information display.

5. Turn the ignition off and then start the engine to verify the indicator has been reset.

When doing the oil change and topping up fluids you will need to use the following specifications:

Engine Size

8 Cyl. 5.7L Gas

Motor Oil

0W20

Oil Capacity w/Filter

7.9 US qt. (7.5L)

Brake Fluid

Dot 3

Engine Coolant

Toyota Super Long Life Coolant

Automatic Transmission

Toyota Genuine ATF WS

Front Differential

Toyota Genuine Differential gear oil LT

75W-85 GL-5 or equivalent

Rear Differential

Toyota Genuine Differential gear oil LT

75W-85 GL-5 or equivalent

Transfer Case

SAE 75W90

You can cross reference the following Purolator filter numbers for your own application:

Engine Size

8 Cyl. 5.7L Gas

Oil Filter

L25702

Air Filter

A55799

Cabin Filter

C35667

8 Cyl. 5.7L

8 Cyl. 5.7L
